Dual Channel Temperature Data Logger Wi-FI based Data Logger

Dual Channel Temperature Data Logger will have two external temperature sensors connected to the device. These sensors are designed to measure and detect temperature changes in their respective environments.

Dual channel Temperature Data Loggers are particularly useful when you need to compare the temperature performance of two different systems or environments side by side. This can help identify anomalies, trends or discrepancies more effectively.

Advantages of Dual Channel Temperature Data Loggers over Single Channel Temperature Data Logger When you have to monitor two places.

  1. Simultaneous Monitoring
  2. Cost Effective [ If you have to monitor two places simultaneously ]
  3. Space Conservation
  4. Efficient Data Comparison
Project Image

Specifications

Device Type Dual Channel (1-Wire)
Model # IBI-WTD120
Temperature Range -50℃ to +120℃
Accuracy ± 0.5℃ (-10℃ to +50℃)
Resolution 0.1℃

Hardware Features

  • 1.3" 128X64 OLED monochrome Graphical Display
  • Internal Li-Ion 2200 mAh battery with under/over protection, up to 24 Hrs battery back-up at sampling frequency of 15 mins during power failure
  • Plug & Play, Wall Mountable Device
  • Wi-Fi 802.11 b/g/n 2.4 GHz
  • Internal Storage of 150 days at sampling frequency of 15 mins
  • DC Input Voltage 5V/1A
  • IP64 Rated

Software Features

  • Different Views (Dashboard / Map / List), Analytics, Device Management, User Management, Alerts Management
  • Custom Reports (21CFR Part 11 Compliance) PDF, CSV
  • MKT Value, Audit Trail, Alarm Log, Trend Graphs
  • Alerts, Push Notifications & SMS (Optional)
  • Web & Mobile Apps (iOS & Android)
